FC Series Fan and Heater Control
Control ventilation and heating with one easy-to-use controller
The Fan and Heater Control (FC-1T-1VAC-1F) automatically controls the temperature in a room by adjusting the speed of variable speed fans and controlling a heater interlock.
Features
- One variable stage
- One heater interlock output
- Automatic shut-off and idle modes
- Adjustable off set-back for shut-off mode (0 to 16°F)
- Adjustable idle speed for idle mode (0 to 99%)
- Adjustable temperature set point, range: 32 to 99°F (0 to 37°C)
- Adjustable temperature differential (1 to 20°F)
- Three-second full-power-turn-on to minimize fan ice-up
- LED display
- Fahrenheit and Celsius display
- Error code display for troubleshooting
- Overload protection fuse
- Six-foot temperature sensor, extendable to 500 feet
- NEMA 4X enclosure (corrosion resistant, water resistant, and fire retardant)
- CSA approval
- Two-year limited warranty
Electrical ratings
Input
- 120/230 VAC, 50/60 Hz
Variable stage
- 10 A at 120/230 VAC, general-purpose (resistive)
- 7 FLA at 120/230 VAC, PSC motor
- 1/2 HP at 120 VAC, 1 HP at 230 VAC, PSC motor
Variable fuse
- 15 A, 250 VAC ABC-type ceramic
Relay
- 10 A at 120/230 VAC, general-purpose (resistive)
- 1/3 HP at 120 VAC, 1/2 HP at 230 VAC
- 360 W tungsten at 120 VAC
